Marine Generators

Keel Cooled Marine

NEXT Generation's KEEL cooled marine gen-sets are designed to be the most rugged commercial duty gen-sets on the market. Constructed of only the finest quality components these gen-sets will provide the longest life spans in the most rugged of environments.

KEEL Cooled Marine Generators

Commercial Duty 1,800 RPM KEEL Cooled Marine Gen-Sets

NEXT Generation's KEEL cooled marine gen-sets are designed to be the most rugged commercial duty gen-sets on the market.  Constructed of only the finest quality components these gen-sets will provide the longest life spans in the most rugged of environments.  Some of the standard features this line includes are:

  • Severe duty Kubota gen-set governed engine with a full 3 year warranty
  • Newage Brushless generator w/marine grade epoxy coated windings
  • Vibration isolated voltage regulator
  • Marine grade pre-tinned wiring harness
  • Oil pressure & water temperature safety shutdown
  • Military spec. vibration isolators
  • Industrial grade air cleaner/intake silencer (Mounted or Remote)
  • Spin on Oil and Fuel filters
  • 12V Starter and Alternator
  • Dry Manifold Dry Exhaust
  • Key Start & HR Meter Mounted





  • 3 phase electrical output
  • 4 gauge deluxe panel remote mountable
  • 10'- 20'- 30' harness
  • Belt guard
  • Steel skid
  • Battery rack and cables (skid mount only)
  • Wet manifold
  • Easy oil change valve
  • Colors: Kubota Blue, Royal Blue, White

Keel Specifications (PDF)

Specifications

Model # # of Cyl. Power kW Engine Model Length Width Height Weight (lbs.)
KCM3-5.0 3 5.0 D-722 34" 18" 21" 375
KCM3-7.0 3 7.0 D-905BG 34" 15.5" 24" 460
KCM3-8.5 3 8.5 D-1005BG 34" 15.5" 24" 460
KCM4-10.5 4 10.5 V-1305BG 38" 15.5" 24" 530
KCM4-12.5 4 12.5 V-1505BG 38" 15.5" 24" 530
KCM4-16.0 4 16.0 V-1903BG 42" 21" 26" 750
KCM4-21.0 4 21.0 V2203BG 44" 21" 26" 775
KCM5-27.0 5 27.0 F-2803BG 52" 21" 27" 975

For more information, please contact sales@nextgenerationpower.com.
